YLIOS make servo stabilizers are one of best latest digital power saving technology in country strictly adhering BIS 9815:1994 standard & can be installed on main incoming supply hence no need to install separate stabilizers for individual system. It provides you smooth supply without any hunting. We are in this field from past 10 years and PAN India presence. We have an expert team that listens to customers' all requirements to make voltage stabilizers. Do make types of servo voltage that are used in many places like industrial and residential purposes. Do make Automatic, Industrial, Single Phase, Three Phase Servo Voltage Stabilizer at a valuable cost in India Basis.

Three phase servo voltage stabilizers are automatic line Voltage corrector using synchronous motor in close loop control. The stabilizer employ continuously variable auto transformer, buck-boost transformer, AC synchronous motor, state of the art IC closed loop control system with all protection, metering, indication and control system to give desired output voltage within the specified limits for a range of input voltages. Provision for manual correction of voltage can also be provided.

• Information Technology and call center
• Commercial Building and Complexes.
• Computers and Micro Processor Control Systems.
• CNC Machines, Laser Machines, Moulding Machines.
• Central Air- Conditioning plants, Processing Plants, Chemical Industries, Textile Industries.
• Defense Installation LPTs, HPTs, Broadcasting, Telecommunications.
• Sophisticated research instruments are used in Medical, agriculture, educational, and other Research Institutions.
• Offset Printing presses, Color Scanners/Processors, Phototypesetters, Photographic Equipment, Photocopiers, and packing industries.
• Petrol Pumps.
• Medical Equipment, X-Ray Machines, ECG Machines/ Monitors, Refrigerated systems, centrifuges, NMR, MRI,
• Oxygen Plant and CT Scanners.
• Air Conditioning Plant

Download PDF

YLIOS is an ISO 9001:2015 certified company and the company is working as Isolation Transformer Manufacturer and provides the best Isolation Transformer & Ultra Isolation Transformer in India. Isolation Transformer is a transformer Used to transfer electrical power from a source of alternating current (AC) power to some equipment or device while isolating the powered device from the power source, usually for safety reasons. Isolation transformers provide galvanic isolation; no conductive path is present between source and load. This isolation is used to protect against electric shock to suppress electrical noise in sensitivity with special insulation between primary and secondary and is specified to withstand a high voltage between windings.

Three phase servo voltage stabilizers are automatic line Voltage corrector using synchronous motor in close loop control. The stabilizer employ continuously variable auto transformer, buck-boost transformer, AC synchronous motor, state of the art IC closed loop control system with all protection, metering, indication and control system to give desired output voltage within the specified limits for a range of input voltages. Provision for manual correction of voltage can also be provided.

YLIOS Isolation power Line Noise Isolator is and ultra-isolation transformer which prevents passage of line voltage transient, spikes and galvanic leakages from reaching sensitive of critical equipment, like Computers & its peripherals, Medical Instrumentation, Digital Communication and Telemetry systems etc.

• Complete Electrostatics Shielding.
• D.C. Insulation <1000 Mega ohms.
• Minimizes Transverse Mode Noise.
• Line and Load Regulation better than ± 3.5%.
• Minimizing Common Mode Noise by Over 130 dB.
• Quality Components, Conservation Ratings and ruggedized design for best Long-Term Value.

Download PDF

Download PDF

Automatic voltage stabilizer has a transformer and a power control circuit for controlling output AC voltage. The control circuit controls the voltage or power automatically and regulates it to a level that is set or required. The basic purpose of a Voltage Stabilizer is to protect the electrical/ electronic gadgets (for example - Air conditioning Unit, Refrigerator, TV, Music System etc.) from probable damage due to Voltage Surge/ fluctuations, Over Voltage, and Under Voltage conditions.

• High & Low Cutoff Feature.
• Thermal Overload Protection
• Inbuilt Time Delay Relay (TDR)
• Power Saving Technology

Download PDF

We are specialized in offering a wide range of "YLios" make three Phase Sequence Corrector that is designed and constructed to meet the demands of sensitive three phase equipment. Crown Enterprises using superior quality of raw material, Automatic Phase Sequence correctors prevent damages at the time when phase is changed or reversed.

• Suitable for correcting the Three phase sequence, whenever the sequence is changed or reversed.
• No break downs of Lifts, UPS, Machineries, 3 Ph. Air conditioner or any motors or 3-phase system due to any change in sequence.
• For Three Phase UPS, during sequence changed or reversed, UPS will start use the battery power & battery may become empty within half or one hour.
• 3 Ph air conditioner will be tripped off, due to sequence reversal & the entire office will be suffering or disturbed because of AC failure.
• Avoid damages during phase sequence changes or reversal.
• The sequence corrector will switch off, during the single phasing or imbalance voltage occur & later, auto-reset after restoration.

YLIOS is an ISO 9001:2015 certified company and the company is working as Isolation Transformer Manufacturer and provides the best Isolation Transformer & Ultra Isolation Transformer in India. Constant Voltage Transformer (CVT) or Ferro resonant Transformer (Ferro) is a non-linear transformer, which passively provides a regulated voltage output through an electromagnetic phenomenon called ferro resonance (where the term ferro resonant transformer was derived). Ferro resonance is associated with the behavior of iron cores while operating near a point of magnetic saturation, wherein the core is so strongly magnetized that further variation in the input voltage results in little or no increase in magnetic flux. Basically, the ferro resonant action is a flux limiter rather than a voltage regulator. Nonetheless, with a fairly constant supply frequency, the CVT can maintain an almost constant output voltage even as the input voltage varies widely. In fact, the output voltage of the ferro varies about 1.2% for every 1% change in supply frequency, such that even with a considerable generator frequency change (2-Hertz), results in an output voltage change of only 4%.

• No moving parts used, hence very high reliability
• Faster voltage correction almost instantaneous
• Intrinsic current limiting and short circuit protection
• Short term over load capability
• Very high line transient/spike rejection capability and excellent input to output isolation characteristics

• Computers & Data Processing
• Telex, Fax, Cash Registers
• Machine Tools, Robotics
• Proto Processing & Biomedical
• Hospitals, Testing Labs
• Control Panels
• Audio/Video Equipment

Download PDF

Single Phase Constant Voltage Transformer (CVT) of other voltage range/ capacity are also available as per customer requirement.

YLIOS is an ISO 9001:2015 certified company and the company is working as Inverter 600VA - 5000VA in India. These inverters assure us high performance, low maintenance, longer working life. Manufactured by experienced engineers, these inverters come with auto start on and stop features. Portable in size, these inverters are ideal solutions for power cuts at homes, offices, clinics, restaurants and other places.

• Auto start & stop function
• Portable in construction

Download PDF

Download PDF

Download PDF
